Flow capacity 38 l/h ... 1.020 l/h RF 410.2-...KM
Admissible counterpressure up to 80 bar

DIMENSIONS
L B

H

115

G

G s B L H s B L H
RF 410.2-38 KM, ...-76 KM G ¾ 100 280 495 490 280 495 490
RF 410.2-150 KM G 1¼ * M10 Ø8,5 533 535 305 514 535
305
RF 410.2-310 KM G 1¼ * PVC, PP, PVDF 305 533 535 1.4571 305 514 535
RF 410.2-510 KM G 1¼ 305 533 535 305 514 535
150
RF 410.2-850 KM G 1¼ 330 130 580 535 330 559 535
* PVC = G1

CHARACTERISTIC CURVES

X

317
