DOSING UNITS, VERTICAL DESIGN

BASIC DESIGNS

CVD 1 s CVD 1

Dosing pump Dosing pump
2-way shut-off valve on the pressure side (Shut off/Emptying) 2-way shut-off valve on the pressure side (Shut off/Emptying)
Diaphragm relief valve Diaphragm relief valve
Wall mounting plat made of PP (H=1.000mm, with drip pan) Wall mounting plat made of PP (H=1.500mm, with drip pan)
Piping on pressure side made of PVC-U or PP Piping on pressure side made of PVC-U or PP
Seals made of EPDM or FPM Seals made of EPDM or FPM

Connection suction side: External thread of pump‘s suction valve Connection suction side: External thread of pump‘s suction valve
Connection pressure side: External thread of final shut-off valve Connection pressure side: External thread of final shut-off valve

Price Price
Type Type
(EUR) (EUR)
CVD 1 s - 60.1 & CVD 1 - 60.1 &
CVD 1 s - 550.1 & CVD 1 - 550.1 &
CVD 1 s - 1500.1 & CVD 1 - 1500.1 &

OPTIONS
Price [EUR]
720.1 (up to 25 l/h) s
Diaphragm pulsation damper
721.2 (up to 50 l/h) s
722.1 (up to 220 l/h) s

723.1 s
713.1 s

Suction side with shut-off valve and line strainer
(not for design CVD1s) s

Feedback pipe from relief valve back to suction side s
(only in combination with suction side pipework)

Multifunction device (priming aid/calibration pot) s

10 l basic version m available without extra charge s available with extra charge 5 not available & on request
