DOSING UNITS, VERTICAL DESIGN

BASIC DESIGNS

CVD 2

2x Dosing pump
2-way shut-off valve on the pressure side (Shut off/Emptying)
Diaphragm relief valves
Wall mounting plat made of PP (H=1.500mm, with drip pan)
Piping on pressure side made of PVC-U or PP
Seals made of EPDM or FPM

Connection suction side: External thread of pump‘s suction valve
Connection pressure side: External thread of final shut-off valve

Price
Type
(EUR)
CVD 2 - 60.1 &
CVD 2 - 550.1 &
CVD 2 - 1500.1 &

OPTIONS

Price [EUR]
Diaphragm pulsation damper 720.1 (up to 25 l/h) s
721.2 (up to 50 l/h) s
722.1 (up to 220 l/h) s

Note: 723.1 s
Use 2 dampers in case of 2 separate pressure sides 713.1 s

Suction side with shut-off valve and line strainer s
(1x each pump)

Suction side connecting piping s
(Pump 1 and pump 2)

Feedback pipe from relief valve back to suction side s
(only in combination with suction side pipework; 1x each pump)

Pressure side connecting piping s
(Pump 1 and pump 2)

Multifunction device (priming aid/calibration pot) s

14 l basic version m available without extra charge s available with extra charge 5 not available & on request
