STEPPER MOTOR DIAPHRAGM PUMPS
coming soon

CONTROLLABLE

Adjustment range 1:1000
OVERVIEW Counterpressure up to 10 bar
Controlled by a microprocessor
Flow capacity 50 l/h

Slow Mode
Timer- and batch-function
Intuitive navigation
Energy-efficient

Robust, corrosion-resistant housing

TECHNICAL DATA Remote control

PUMP DATA iSTEP XS 7 iSTEP XS 15

Permissible pressure p 2max. bar 10 7 coming soon
at the pump outlet
Nominal capacity QN
at p l/h 7 15
2max.
Capacity min. (1:1000) l/h 0,007 0,015
Quantity per stroke ml/Stroke (100%) 0,61 1,47
Max. suction height mWS 3 3
Min./max. permissible bar p -0,3/0,5 -0,3/0,5
pressure at the pump inlet 1min/max
Recommended nominal diame- mm 3 5
ter DN of the connecting pipes
Nominal stroke frequency 1/min 190 170
plastic 3,6 3,6
Weight approx. kg
stainless steel 4,0 4,0

ELECTRICAL DATA iSTEP XS...

Power consumption W 45
Voltage V 100 - 240 AC
Frequency Hz 50/60
Insulation class ISO F

Recommended fuse (circuit breaker) C10A
Enclosure
Certifications

80
