STEPPER MOTOR DIAPHRAGM PUMPS
Diaphragm coming soon

CONTROLLABLE

FUNCTIONS AND OPERATING MODES

● Extremely wide performance range ● Intuitive menu navigation ● 3 Inputs:
● Adjustment range 1:1000 incl. parameterization 3 programmable as digital inputs
thus optimally adoptable ● Pulse division or multiplication or
● Low pulsation dosage ● Weekly/daily timer operation 2 programmable as analogue inputs
● Drive controlled by microprocessor ● 8 languages for the menu 0/4...20mA
● Flexible remote control (de, en, es, fr, nl, cs, fi, tr) ● 2 Digital outputs
● Slow mode for viscous media ● Certified accord. to TR (EAC) ● 1 Analogue output for 0/4...20 mA signal
● Energy-efficient drive technology ● removable graphic display with back light ● All outputs are free programmable
● Batch dosing with recipe memory ● Incl. 5m control cable (8-pole)
● Incl. 2m connection cable with Euro-plug

BASIC DESIGNS

PP PVDF
XS 7 XS 15 XS 7 XS 15
Pump body PP-FRP Pump body PVDF-FRP
Valves PP PP-FRP Valves PVDF PVDF-FRP
Valve balls Ceramic PTFE Valve balls Ceramic PTFE
Diaphragm PTFE-faced Diaphragm PTFE-faced
Valve seals Valve seals
Type EPDM Price FPM Price Type FEP-covered Price
Article-No. (EUR) Article-No. (EUR) Article-No. (EUR)
iSTEP XS 7 15006847 & 15006848 & iSTEP XS 7 15006851 &
iSTEP XS 15 15006853 & 15006854 & iSTEP XS 15 15006857 &

PVC-U STAINLESS STEEL
XS 7 XS 15 XS 7 XS 15
Pump body PVC-U Pump body 1.4571
Valves PVC-U Valves 1.4571 1.4571/1.4581
Valve balls Ceramic PTFE Valve balls Ceramic 1.4401
PTFE-faced Diaphragm PTFE-faced
Valve seals Valve seals
Type EPDM Price FPM Price Type FEP-covered Price
Article-No. (EUR) Article-No. (EUR) Article-No. (EUR)
iSTEP XS 7 15006849 & 15006850 & iSTEP XS 7 15006852 &
iSTEP XS 15 15006855 & 15006856 & iSTEP XS 15 15006858 &

82 l basic version m available without extra charge s available with extra charge 5 not available & on request
