MULTI-LAYER DIAPHRAGM PUMPS

CONTROLLABLE

FITTINGS FOR THE PRESSURE SIDE

Flow meter

l IP65
l incl. 0,6m cable with cable socket M12, 5-pole (socket for pump connection)
l max. permissible operating pressure: 10 bar
l can be used on suction and pressure side

Type Connection thread Materials Article-No. Price (EUR)
Inlet: G¾ (internal) PVC-U/FPM 37602322 s
8016.1 Outlet: G¾ (external) PVDF/FPM & &

Diaphragm pulsation damper (Plastic, PTFE(-faced) diaphragm, max. 10 bar)
Properties
l Any mounting position l Easy handling l Diaphragm: PTFE-faced
l Easy installation l High-quality materials
l Long service life l Low maintenance

Type Connection max. Pressure Material Seals Article-No. Price (EUR)

C410.2-135 ML
722.1 G 1 10 bar PVC-U EPDM 37600647 s
722.1 G 1 10 bar PVC-U FPM 30100008 s
722.1 G 1 10 bar PP EPDM 37600676 s
722.1 G 1 10 bar PP FPM 30100009 s
722.1 G 1 10 bar PVDF FEP 37601852 s
C410.2-500 ML
& & &

ACCESSORIES

Filling pump FLP 2 for filling device
with manometer, max. 7 bar incl. 2m hose and coupling for air valve 90009396 s

Retaining clamp

(2 Piece each pulsation damper) PP d 25 90010651 s

188 l basic version m available without extra charge s available with extra charge 5 not available & on request
