CONNECTION Suction-/Pressure side: G1 1/2 (f) AP...-340
Max. flow capacity 340 l/min
Admissible counterpressure up to 8 bar

ACCESSORIES

Commpressed air supply unit

l Filter prssure controller l incl. 5m pneumatic hose
l Shut-off and check valve
l Fittings * design for hazardous areas on request Article-No. Price (EUR)
without solenoid valve 90019999 s
for APB-Design 24 V 90020027 s
with solenoid valve (incl. double nipple)* 230 V 90020020 s

for APE-Design 24 V &
with solenoid valve (incl. double nipple)* 230 V &

Connection adapter

l two pieces are required per pump
Pump connection Adapter connections Material Seals Article-No. Price (EUR)

G 1 1/2 G1 1/2 - G2 1/4 PP EPDM 90044752 s
G 1 1/2 G1 1/2 - G2 1/4 PP FPM 90044758 s
G 1 1/2 G1 1/2 - G2 1/4 1.4571 FEP 90044763 s

FITTINGS FOR THE PRESSURE SIDE

Diaphragm pulsation damper
Properties
l Compact design l Maintenance free
l Any mounting direction l High quality materials

Type Ex-Zone Connection Housing Diaphragm Article-No. Price (EUR)
APB-340
MPD-340 II 3G EEx c IIB T4 G1 1/2 PP Hytrel-PTFE 37601314 s
MPD-340 II 3G EEx c IIB T4 G1 1/2 PVDF Santo-PTFE 37606670 s
MPD-340 II 3G EEx c IIB T4 G1 1/2 PPS-V Hytrel-PTFE & s
APE-340
MPD-340 II 2G EEx c IIB T4 G1 1/2 PP-CFK Hytrel-PTFE 37604859 s
MPD-340 II 2G EEx c IIB T4 G1 1/2 PVDF-CFK Santo-PTFE 37605763 s

l basic version m available without extra charge s available with extra charge 5 not available & on request 375
